SC904-001-01 by Pacific Scientific
Get a Quote for SC904-001-01
Request a quote or call us now at 1-919-443-0207!
In Stock, Ships Today
We respect your privacy. Your information is safe and will never be shared.
Secure Online
Checkout
Free Ground
Shipping
One Year
Warranty
The SC904-001-01 is a servo drive manufactured by Pacific Scientific. As part of the SC900 Series, this unit has a bus voltage of 320 volts DC. The continuous current rating is 15 amps, and the peak current reaches 30 amps. The device operates with an input voltage ranging from 90 to 264 volts AC.
Technical Specifications
Product type
Servo drive
Servo drive
Manufacturer
Kollmorgen
Kollmorgen
Option card
None
None
Continuous current
15 Amps
15 Amps
Peak current
30 Amps
30 Amps
Customization code
Standard unit
Standard unit
Fimrware
Base Servo Software
Base Servo Software
Input voltage
90 to 264 Volts AC
90 to 264 Volts AC
Transformer
3 to 6 kVA
3 to 6 kVA
Bus voltage
320 Volts DC
320 Volts DC
