SC125-410-T4 by Pacific Scientific

Rated 4.3 stars (9 reviews)

Get a Quote for  SC125-410-T4

Request a quote or call us now at 1-919-443-0207!

Call For Quote

We respect your privacy. Your information is safe and will never be shared.

Secure Online
Checkout

Free Ground
Shipping

One Year
Warranty

The SC125-410-T4 controller from Pacific Scientific is part of the SC100 Brushless Servo Controllers series. It accepts 230V AC 3-phase 30KVA input at 50/60Hz and uses bottom cooling fans (230VAC, 0.08A) plus two 2200 µF capacitors. Built-in dynamic braking via Regen terminals and MOV-protected input ensure energy recovery and fault protection. The unit operates from 0 to 50°C (full rating) and up to 60°C when derated.

Technical Specifications

Actuation
Supports brushless actuators and inverters
Capacitors
Two 2200 µF capacitors
Component Designation
SC125-410-T4
Cooling
Bottom cooling fans for heat dissipation
Drive Input
DC Driven operations
Dynamic Braking
Built-in dynamic braking system
Fan
Operates at 230VAC, 0.08A current
Input current
30KVA
Input frequency
50/60Hz
Input voltage
230V AC
Manufacturing Label
Pacific Scientific
Output Voltage
Compatible with brushless servo motors
phases
3PH
Protection
MOV protected input circuitry, fusing
Temperature Range
0°C to 50°C (full), 50°C to 60°C (derated)

Click here for product datasheet
