The M22NRXD-LNN-NS-00 stepper motor is equipped with samarium-cobalt magnets, uses convection cooling, features metallic housing, and has a NEMA 23 standard mounting frame size. As part of Pacific Scientific's POWERMAX II M Series, this motor connects through connector pins and is suitable for installation up to 1000 meters above sea level.
Technical Specifications
Frame size
NEMA 23 standard mounting
NEMA 23 standard mounting
Magnet type
Samarium-cobalt magnets
Samarium-cobalt magnets
Technology
POWERMAX II® Hybrid Motor Technology
POWERMAX II® Hybrid Motor Technology
Step angle
1.8 degrees
1.8 degrees
Housing
Metallic
Metallic
Cooling type
Convection
Convection
Alllowable installation height
1000 meters above sea level
1000 meters above sea level
Mounting
Using 4 through holes
Using 4 through holes
Warranty
1 year
1 year
Connection
Through connector pins
Through connector pins
