M21NSXC-LSS-SS-02 by Pacific Scientific
Get a Quote for M21NSXC-LSS-SS-02
Request a quote or call us now at 1-919-443-0207!
In Stock, Ships Today
We respect your privacy. Your information is safe and will never be shared.
Secure Online
Checkout
Free Ground
Shipping
One Year
Warranty
The M21NSXC-LSS-SS-02 exhibits a holding torque of 1.02 Nm, phase inductance of 8.0 mH, and rated current per phase of 3.5 Amps DC. Part of the POWERMAX II M Series by Pacific Scientific, it features a detent torque of 0.66 Nm and thermal resistance of 5.5°C/W mounted.
Technical Specifications
Detent Torque
0.66 Nm
0.66 Nm
Holding Torque
1.02 Nm
1.02 Nm
Phase Inductance
8.0 mH Typical
8.0 mH Typical
Phase Resistance
2.12 ohms -/+ 10%
2.12 ohms -/+ 10%
Rated Current/ Phase
3.5 Amps DC
3.5 Amps DC
Thermal Resistance
5.5 Mounted degree Celsius/ Watt
5.5 Mounted degree Celsius/ Watt
