BA3648-5502-9-48B by Pacific Scientific

Name: BA3648-5502-9-48B
Brand: Pacific Scientific
Price: 151 USD
Availability: InStock
Rating: 4.7 (23 reviews)

Rated 5.0 stars (25 reviews)

Manufacturer image of Pacific Scientific

Get a Quote for BA3648-5502-9-48B

Request a quote or call us now at 1-919-443-0207 !

In-Stock, Ships 3-5 Days

We respect your privacy. Your information is safe and will never be shared.

Secure Online
Checkout

Free Ground
Shipping

One Year
Warranty

The Pacific Scientific BA Permanent Magnet DC (PMDC) Series is renowned for its robust construction and reliable operation, making it ideal for rugged industrial applications. Operating within low voltage NEMA standards, these motors feature Class H armature insulation and patented anti-cogging magnets, ensuring smooth performance even at low speeds. Their polyester-impregnated armature and rugged fused commutator contribute to their electrical and mechanical integrity, while large sealed bearings enhance durability. Available in TEFC and TENV configurations, these legacy motors have maintained popularity due to their long-standing reliability and cost-effectiveness.

Technical Specifications

Bearings
Large sealed

Bolt Circle Diameter
5.875 in

Brushes
Field replaceable

Certification
NEMA standards; UL recognized; CSA listed

Cooling Options
TEFC or TENV

Enclosure
48B low voltage

Motor Type
Permanent Magnet DC

Mounting Bolt Count
4 × 3/8-16 UNC-2B bolts

Mounting Configuration
NEMA C-face with removable base

Operating Temperature
-10°C to +40°C

Rated Output
0.75 HP

Service Factor
1.15

Shaft Key Size
0.188 × 1.38 in

Speed
1750 RPM

Thermal Overload Protection
Automatic

Click here for product datasheet
