The MIP22 D22 is a spindle inverter unit manufactured by Okuma. Part of the MIV Servo Drives series, it delivers 22 kW (30 hp) spindle capacity with a DC bus current of 176 A/V. The unit measures 310 mm x 200 mm x 733 mm and weighs 43 kg. A 7-segment LED display shows operation and error codes for real-time diagnostics.
Technical Specifications
Control Board Model
IPCB
IPCB
Control Board Order Number
1006-2106
1006-2106
Cutout Dimensions
714mm (28.11in) height, 200mm (7.87in) width
714mm (28.11in) height, 200mm (7.87in) width
Dc Bus Current
176 A/V (Applicable to MIP22)
176 A/V (Applicable to MIP22)
Dimensions
310mm (12.20in) x 200mm (7.87in) x 733mm (28.86in)
310mm (12.20in) x 200mm (7.87in) x 733mm (28.86in)
Display Indicator
7-segment LED for operation and error status
7-segment LED for operation and error status
Inverter Unit Model (ha)
1006-2239
1006-2239
Inverter Unit Model (ni)
1006-2238
1006-2238
Motor Capacity
22 kW (30 hp)
22 kW (30 hp)
Motor Current
131.1 A/V (Applicable to MIP22)
131.1 A/V (Applicable to MIP22)
Mounting Hole Configuration
4-M8
4-M8
Rated Motor Output
30/22 kW (40/30 hp)
30/22 kW (40/30 hp)
Type
Spindle Motor Drive Inverter Unit
Spindle Motor Drive Inverter Unit
Weight
43 kg (94.6 lbs)
43 kg (94.6 lbs)
