The AKM42E-ACCNR-00 synchronous servo motor has a frame size of NEMA 42, a holding torque of 239 oz-in (1.69 Nm), a phase resistance of 0.13 Ohms, and weighs 3.2 lb (1.45 kg). Part of the AKM Synchronous Servo Motors series manufactured by Kollmorgen, it features an IEC accuracy N flange and a resolver feedback system.
Technical Specifications
Brake System
Without brake
Without brake
Connector Arrangement
2 SpeedTec Ready connectors
2 SpeedTec Ready connectors
Customization Level
Standard
Standard
Feedback System
Resolver
Resolver
Flange Configuration
IEC with accuracy N
IEC with accuracy N
Frame Dimension
84mm
84mm
Product Family
AKM Synchronous Servo Motor
AKM Synchronous Servo Motor
Rotor Length Index
2
2
Shaft Detail
Keyway
Keyway
Winding Designation
e
e
Max Length L1
5.61 inch [142.49 mm]
5.61 inch [142.49 mm]
Weight
3.2 lb (1.45 kg)
3.2 lb (1.45 kg)
Radial Force
35 lbs (156 N)
35 lbs (156 N)
Max Diameter
4.25 inch [107.95 mm]
4.25 inch [107.95 mm]
Phase Resistance
0.13 Ohms
0.13 Ohms
Thermal Resistance
3.9 degrees C/Watt
3.9 degrees C/Watt
Shaft Diameter
0.375 inch [9.53 mm]
0.375 inch [9.53 mm]
