M112-FF-206 by Danaher
Get a Quote for M112-FF-206
Request a quote or call us now at 1-919-443-0207!
In Stock, Ships Today
We respect your privacy. Your information is safe and will never be shared.
Secure Online
Checkout
Free Ground
Shipping
One Year
Warranty
The Danaher M112-FF-206, part of the Slo-Syn Stepping Motors series, is a bipolar stepper motor with a square flange. It operates at 3.0 VDC with a peak current of 6.0 A, has a phase inductance of 8.8 mH, and a step angle of 1.8 degrees per step. Sealed against dust and liquids, it supports up to 100°C case temperature.
Technical Specifications
Electrical Resistance
0.49 ?
0.49 ?
Environmental Protection
Sealed against dust & liquids
Sealed against dust & liquids
Flange Type
Square (SQ)
Square (SQ)
Industry Certifications
UL Class I, Div. 1; ISO
UL Class I, Div. 1; ISO
Max Case Temperature
100 °C
100 °C
Motor Type
Bipolar stepper, 4-wire
Bipolar stepper, 4-wire
Peak Current
6.0 A
6.0 A
Phase Inductance
8.8 mH
8.8 mH
Position Accuracy
±5%
±5%
Rated Voltage
3.0 VDC
3.0 VDC
Step Angle
1.8° per step
1.8° per step
Winding Configuration
Bipolar
Bipolar
