The 21BRCX-510-D7B/10 resolver by Danaher is part of the Dynapar Resolvers series. It features a steel housing, a 2.1-inch frame size, a housing length of 1.25 inches, and operates up to 200°C. The device uses an 8 kHz excitation frequency, accepts 8 Vrms input voltage, and draws 46 mA input current for efficient signal transmission. It has a transformation ratio of 0.50 and a servo groove that is not present.
Technical Specifications
8 kHz
21
2.061 in
510 (D7B/10 variant)
1.25 in
Steel
46 mA
8 Vrms
84 mV RMS
? 200°C
2.1 in
260 ?
Not present
565 ?
BRCX single/multiple-speed, rotor primary
0.50
