The M.1300.6042 module from Danaher's Block IO Analog Modules series is an 8 in/8 out discrete I/O module for MMC systems. It runs on 24 VDC (20–30 VDC) and provides 4 A continuous output per group with a 5 A switch rating and 1 ms maximum switching time. Yellow LEDs indicate input/output status, a red LED signals short-circuit, and the module tolerates a 2.5 A inrush at power-on. Field-side connection is via two 18-pin screw-terminal connectors.
Technical Specifications
4 A per output group
Two 18-pin screw-terminal connectors
5 VDC
15 VDC
0 V off, 24 V on per IEC Type 1
Yellow per input
2.5 A at power-on
7.5 mA at 30 VDC
8 in/8 out discrete I/O for MMC system
100 mA at 24 VDC
Yellow per output
Red
24 VDC (range 20-30 VDC)
25 A, 130 µs pulse every 100 ms
5 A per output
1 ms on/off max
