VT-MRPA2-1-1X/V by Bosch Rexroth Indramat
Get a Quote for VT-MRPA2-1-1X/V
Request a quote or call us now at 1-919-443-0207!
In Stock, Ships Fast
We respect your privacy. Your information is safe and will never be shared.
Secure Online
Checkout
Free Ground
Shipping
One Year
Warranty
The VT-MRPA2-1-1X/V proportional amplifier operates at 24 VDC (18 to 35 V), features a ramp time range of 20 ms to 5 s, consumes less than 50 VA, and offers a zero adjustment range of ±30%. Part of the VT-VSPA Proportional Amplifiers series by Bosch Rexroth Indramat, it measures Euro-card 100 x 160 mm and includes a one-year warranty.
Technical Specifications
Card Dimensions
Euro-card 100 x 160 mm (DIN 41494)
Euro-card 100 x 160 mm (DIN 41494)
Command Value Inputs (1 To 4)
0 ... ±10 V with input impedance > 100 k?
0 ... ±10 V with input impedance > 100 k?
Command Value Setting Range
0 ... 110% (for potentiometers w1 to w4)
0 ... 110% (for potentiometers w1 to w4)
Current Consumption
< 2 A
< 2 A
Current Input (command Value 6)
4 ... 20 mA (load RB = 100 ?)
4 ... 20 mA (load RB = 100 ?)
Differential Input (command Value 5)
0 ... ±10 V with input impedance > 50 k?
0 ... ±10 V with input impedance > 50 k?
External Ramp Time Input
0 ... +10 V (internally increased to +15 V, Re = 10 k?)
0 ... +10 V (internally increased to +15 V, Re = 10 k?)
Internal Command Value Output
±10 V ±2% with Imax = 2 mA
±10 V ±2% with Imax = 2 mA
Operating Range
18 V (min) to 35 V (max)
18 V (min) to 35 V (max)
Operating Voltage
24 VDC (+40% / -20%)
24 VDC (+40% / -20%)
Power Consumption
< 50 VA
< 50 VA
Ramp Time Range
20 ms ... 5 s (switchable to 0.2 ... 50 s)
20 ms ... 5 s (switchable to 0.2 ... 50 s)
Step Level Range
0 ... 50%
0 ... 50%
Warranty
One-year
One-year
Zero Adjustment Range
0 to ±10%
0 to ±10%
