The MSK076C-0300-NN-S1-UP0-NNNN is a synchronous servomotor produced by Bosch Rexroth Indramat within the MSK IndraDyn S Synchronous Motors series. The unit is used in packaging lines, handling robots, and tool axes. It converts drive-generated three-phase power into precisely controlled torque and speed so that motion sequences follow PLC setpoints with tight positional repeatability.

The 0300 winding allows the motor to generate a peak torque of 43.5 Nm, giving machinery enough reserve to overcome acceleration loads without oversizing the drivetrain. When supplied from a 750 V DC bus, the rotor can reach a top mechanical speed of 4700 rpm, supporting high-speed movements in short-cycle applications. Drive electronics may command up to 32.4 A during such peaks, while Class 155 insulation tolerates the resulting winding temperature rise. The housing has an IP65 protection rating, allowing installation where dust or water jets are present. Heat is removed through natural convection, so no external blower or liquid circuit is required. The rotor has an inertia of 0.0043 kg·m², balancing fast response with stable velocity regulation. Because the shaft is supplied without a holding brake, any static load must be secured by the drive or external mechanics.

The centering pilot measures 110 mm, while the mounting bolt circle measures 165 mm; these dimensions match common IEC gearbox flanges for straightforward integration. A 140 mm frame flange and a C-length stator keep the overall depth moderate. The keyed steel shaft is 24 mm in diameter and 50 mm long, transferring motion without slipping. Feedback is provided by an optical single-turn encoder using the Hiperface interface, and its 240° rotatable connector facilitates cable routing in tight spaces. The motor has a mass of 13.8 kg, which allows easier handling while providing sufficient thermal mass for continuous operation. The permitted ambient operating temperature ranges from 0 to 40 °C.

Technical Specifications

Centering Diameter
110 mm

Cooling
Natural convection

Design
Standard

Encoder Connector
Rotatable, 240°

Encoder Interface
Hiperface

Encoder Resolution
128 signal periods

Encoder Technology
Optical

Encoder Turn Type
Singleturn

Flange Size
140 mm

Holding Brake
Without holding brake

Max Current
32.4 A

Max Speed (750 V Dc)
4700 rpm

Max Torque
43.5 Nm

Motor Length
C

Motor Size
076

Mounting Circle Dia
165 mm

Operating Ambient Temperature Range
0-40°C

Product Type
IndraDyn S Synchronous Servomotor

Protection Rating
IP65

Rotor Inertia
0.0043 kg·m²

Shaft Diameter
24 mm

Shaft Length
50 mm

Shaft Type
Shaft with keyway

Thermal/Insulation Class
155

Weight
13.8 kg

Winding Code
0300
