MKD112C-058-GG0-AN by Bosch Rexroth Indramat
Get a Quote for MKD112C-058-GG0-AN
Request a quote or call us now at 1-919-443-0207!
In Stock, Ships 2-3 Days
We respect your privacy. Your information is safe and will never be shared.
Secure Online
Checkout
Free Ground
Shipping
One Year
Warranty
The Bosch Rexroth Indramat MKD112C-058-GG0-AN is part of the MKD Synchronous Motors, featuring natural cooling. This motor delivers a power output of 9.3 kW with a rated torque of 60 Nm and a rated speed of 3000 RPM. It has a weight of 58 kg and boasts IP65 protection, suitable for various demanding environments.
Technical Specifications
Driven Shaft
Plain Shaft
Plain Shaft
Holding Brake
Not Equipped
Not Equipped
Motor Feedback
Resolver feedback
Resolver feedback
Windings Code
058
058
Motor Type
Synchronous Motor
Synchronous Motor
Rated Speed
3000 RPM
3000 RPM
Rated Torque
60 Nm
60 Nm
Power Output
9.3 kW
9.3 kW
Rated Voltage
300V
300V
Rated Current
33A
33A
Cooling Method
Natural cooling
Natural cooling
Encoder Type
Digital
Digital
Weight
58 kg
58 kg
Length
445 mm
445 mm
Flange Size
192 x 192 mm
192 x 192 mm
Protection Class
IP65
IP65
Max Speed
4500 RPM
4500 RPM
Inertia
0.0122 kgm²
0.0122 kgm²
Overload Capacity
300%
300%
