MKD112C-024-KP3-AN by Bosch Rexroth Indramat
Get a Quote for MKD112C-024-KP3-AN
Request a quote or call us now at 1-919-443-0207!
In Stock, Ships Today
We respect your privacy. Your information is safe and will never be shared.
Secure Online
Checkout
Free Ground
Shipping
One Year
Warranty
The Bosch Rexroth Indramat MKD112C-024-KP3-AN is part of the MKD Synchronous Motors series and features natural convection cooling. Its rated speed is 3000 RPM, producing a rated torque of 24 Nm, with a protection class of IP65. The motor's peak current is 65 A and it weighs 48 kg.
Technical Specifications
Driven Shaft
Shaft with Key
Shaft with Key
Holding Brake
Equipped
Equipped
Motor Feedback
Resolver feedback with integrated multiturn absolute encoder
Resolver feedback with integrated multiturn absolute encoder
Windings Code
024
024
Type
Synchronous Motor
Synchronous Motor
Rated Speed
3000 RPM
3000 RPM
Cooling Mode
Natural Convection
Natural Convection
Connection
Star
Star
Power
7.3 kW
7.3 kW
Voltage Constant (ke)
136 V/1000min^-1
136 V/1000min^-1
Torque Constant (kt)
1.05 Nm/A
1.05 Nm/A
Rated Torque
24 Nm
24 Nm
Rated Current
22.3 A
22.3 A
Peak Current
65 A
65 A
Rotor Inertia
0.0933 kg*m^2
0.0933 kg*m^2
Weight
48 kg
48 kg
Protection Class
IP65
IP65
Feedback
Resolver
Resolver
