The Bosch Rexroth Indramat MKD112C-024-GP0-RN is a synchronous motor from the MKD Synchronous Motors series with a power rating of 24 kW. This motor has a speed of 3000 RPM and operates at a voltage of 320 V with a current of 60 A. It features resolver feedback and a sealed housing, ensuring IP65 protection.
Technical Specifications
Driven Shaft
Shaft with Key
Shaft with Key
Holding Brake
Not Equipped
Not Equipped
Motor Feedback
Resolver feedback
Resolver feedback
Windings Code
024
024
Type
Synchronous Motor
Synchronous Motor
Power Rating
24 kW
24 kW
Voltage
320 V
320 V
Current
60 A
60 A
Speed
3000 RPM
3000 RPM
Torque
70 Nm
70 Nm
Cooling Method
Natural Convection
Natural Convection
Encoder Type
Resolver
Resolver
Protection Class
IP65
IP65
Housing
Sealed
Sealed
Weight
50 kg
50 kg
Ambient Temperature
0 to 40 °C
0 to 40 °C
Insulation Class
F
F
