MKD112B-058-KG0-AN by Bosch Rexroth Indramat
Get a Quote for MKD112B-058-KG0-AN
Request a quote or call us now at 1-919-443-0207!
In Stock, Ships 2-3 Days
We respect your privacy. Your information is safe and will never be shared.
Secure Online
Checkout
Free Ground
Shipping
One Year
Warranty
The MKD112B-058-KG0-AN motor offers resolver feedback with an integrated multiturn absolute encoder, a moment of inertia of 10.4 kgm², and IP65 protection. Part of the MKD Synchronous Motors series by Bosch Rexroth Indramat, it features natural convection cooling and a rated power of 6 kW.
Technical Specifications
Driven Shaft
Plain Shaft
Plain Shaft
Holding Brake
Not Equipped
Not Equipped
Motor Feedback
Resolver feedback with integrated multiturn absolute encoder
Resolver feedback with integrated multiturn absolute encoder
Windings Code
058
058
Motor Type
Synchronous Motor
Synchronous Motor
Connection
Star
Star
Number Of Pole Pairs
4
4
Cooling Type
Natural Convection
Natural Convection
Rated Power
6 kW
6 kW
Rated Torque
36 Nm
36 Nm
Maximum Standstill Torque
70 Nm
70 Nm
Rated Speed
1500 rpm
1500 rpm
Maximum Speed
9000 rpm
9000 rpm
Voltage Constant
67 V/1000 rpm
67 V/1000 rpm
Torque Constant
1.19 Nm/A
1.19 Nm/A
Moment Of Inertia
10.4 kgm²
10.4 kgm²
Weight
63 kg
63 kg
Protection Class
IP65
IP65
