MKD112B-048-KP1-AN by Bosch Rexroth Indramat
Get a Quote for MKD112B-048-KP1-AN
Request a quote or call us now at 1-919-443-0207!
In Stock, Ships Today
We respect your privacy. Your information is safe and will never be shared.
Secure Online
Checkout
Free Ground
Shipping
One Year
Warranty
The MKD112B-048-KP1-AN synchronous motor from the Bosch Rexroth Indramat MKD Series features digital servo feedback. It operates at a rated speed of 4,000 min^-1 with a rated power of 4.2 kW and a maximum speed of 6,000 min^-1. Its protection class is IP65 and it has a peak torque of 42 Nm.
Technical Specifications
Driven Shaft
Shaft with Key
Shaft with Key
Holding Brake
Equipped
Equipped
Motor Feedback
Resolver feedback with integrated multiturn absolute encoder
Resolver feedback with integrated multiturn absolute encoder
Windings Code
048
048
Motor Type
Synchronous Motor
Synchronous Motor
Rotor Type
Smooth
Smooth
Cooling Mode
Natural convection
Natural convection
Coating
Standard
Standard
Rated Speed
4,000 min^-1
4,000 min^-1
Max Speed
6,000 min^-1
6,000 min^-1
Moment Of Inertia
22.6 kg·cm²
22.6 kg·cm²
Motor Weight
25 kg
25 kg
Rated Torque
10.5 Nm
10.5 Nm
Peak Torque
42 Nm
42 Nm
Rated Power
4.2 kW
4.2 kW
Rated Voltage
370 V
370 V
Rated Current
8.1 A
8.1 A
Protection Class
IP65
IP65
Feedback Type
Digital servo feedback
Digital servo feedback
