The MKD112B-048-GG0-BN motor features a basic black housing finish and provides a peak current of 148 A. Designed by Bosch Rexroth Indramat, it belongs to the MKD Synchronous Motors series and has a mass of 34 kg. The motor operates at a nominal speed of 3500 min-1, comes with resolver feedback, and has plug-in electrical connectors.
Technical Specifications
Driven Shaft
Plain Shaft
Plain Shaft
Holding Brake
Not Equipped
Not Equipped
Motor Feedback
Resolver feedback
Resolver feedback
Windings Code
048
048
Nominal Motor Speed
3500 min-1
3500 min-1
Torque At Standstill (natural Convection)
28.0 Nm
28.0 Nm
Torque At Standstill (surface Cooled)
42.0 Nm
42.0 Nm
Current At Standstill (natural Convection)
35.6 A
35.6 A
Current At Standstill (surface Cooled)
53.4 A
53.4 A
Theoretical Maximum Torque
102 Nm
102 Nm
Peak Current
148 A
148 A
Moment Of Inertia Of Rotor
192 x 10^-4 kgm²
192 x 10^-4 kgm²
Torque Constant At 20ºc
0.88 Nm/A
0.88 Nm/A
Voltage Constant At 20ºc
80.0 V/1000 min-1
80.0 V/1000 min-1
Windings Resistance At 20ºc
0.37 Ohm
0.37 Ohm
Windings Inductance
4.8 mH
4.8 mH
Thermal Time Constant (natural Convection)
90 min
90 min
Thermal Time Constant (surface Cooled)
60 min
60 min
Mass
34 kg
34 kg
Electrical Connections
Plug-in connector
Plug-in connector
Allowable Ambient Temperatures
0 to +45 ºC
0 to +45 ºC
Storage And Transport Temperature
-20 to +80 ºC
-20 to +80 ºC
Maximum Installation Elevation
1000 m above sea level
1000 m above sea level
Protection Category
IP 65
IP 65
Insulation Class
F
F
Housing Finish
Basic black coat (RAL 9005)
Basic black coat (RAL 9005)
