The Bosch Rexroth Indramat MKD112A-058-KG1-AN is part of the MKD Synchronous Motors series and has a terminal box connection type. With a peak torque of 84 Nm and a rated current of 30 Amps, it also provides resolver feedback with an integrated multiturn absolute encoder. This 35 kg motor offers natural convection cooling and maintains an IP65 protection class.
Technical Specifications
Plain Shaft
Equipped
Resolver feedback with integrated multiturn absolute encoder
058
Synchronous Motor
4.9 kW
115 V
30 A
28 Nm
84 Nm
1500 RPM
4500 RPM
0.0113 kg·m²
35 kg
Resolver
IP65
Natural Convection
F
Terminal Box
112 mm
