MKD112A-058-KG0-BN by Bosch Rexroth Indramat
Get a Quote for MKD112A-058-KG0-BN
Request a quote or call us now at 1-919-443-0207!
In Stock, Ships 2-3 Days
We respect your privacy. Your information is safe and will never be shared.
Secure Online
Checkout
Free Ground
Shipping
One Year
Warranty
The Bosch Rexroth Indramat MKD112A-058-KG0-BN is part of the MKD Synchronous Motors series with a motor frame size of 112 mm. It features a digital servo feedback encoder and a standard cooling method with a maximum current of 84 Amps. The motor possesses a protection class of IP65 and a maximum torque of 118 Nm.
Technical Specifications
Driven Shaft
Plain Shaft
Plain Shaft
Holding Brake
Not Equipped
Not Equipped
Motor Feedback
Resolver feedback with integrated multiturn absolute encoder
Resolver feedback with integrated multiturn absolute encoder
Windings Code
058
058
Motor Type
Synchronous Servo Motor
Synchronous Servo Motor
Number Of Phases
3
3
Cooling Method
Standard cooling
Standard cooling
Rated Speed
Up to 3000 RPM
Up to 3000 RPM
Rated Torque
39 Nm
39 Nm
Maximum Torque
118 Nm
118 Nm
Rated Current
28.5 A
28.5 A
Maximum Current
84 A
84 A
Rated Voltage
315 V
315 V
Maximum Voltage
460 V
460 V
Moment Of Inertia
0.012 kgm²
0.012 kgm²
Protection Class
IP65
IP65
Motor Frame Size
112 mm
112 mm
Connection Type
Connector
Connector
Encoder Type
Digital Servo Feedback
Digital Servo Feedback
Weight
29 kg
29 kg
