MKD112A-058-KG0-AN by Bosch Rexroth Indramat
Get a Quote for MKD112A-058-KG0-AN
Request a quote or call us now at 1-919-443-0207!
In Stock, Ships 2-3 Days
We respect your privacy. Your information is safe and will never be shared.
Secure Online
Checkout
Free Ground
Shipping
One Year
Warranty
The MKD112A-058-KG0-AN motor boasts a maximum power of 26 kW, a maximum torque of 100 Nm, and employs self-cooling. As part of the Bosch Rexroth Indramat MKD Synchronous Motors series, it features a rated speed of 3000 min-1 and operates at 400V.
Technical Specifications
Driven Shaft
Plain Shaft
Plain Shaft
Holding Brake
Not Equipped
Not Equipped
Motor Feedback
Resolver feedback with integrated multiturn absolute encoder
Resolver feedback with integrated multiturn absolute encoder
Windings Code
058
058
Motor Type
MKD
MKD
Voltage Class
400V
400V
Rated Speed
3000 min-1
3000 min-1
Maximum Speed
8000 min-1
8000 min-1
Rated Torque
29 Nm
29 Nm
Maximum Torque
100 Nm
100 Nm
Rated Power
7.8 kW
7.8 kW
Maximum Power
26 kW
26 kW
Inertia
0.0100 kgm^2
0.0100 kgm^2
Weight
34 kg
34 kg
Cooling Method
Self-cooling
Self-cooling
Encoder
Inductive encoder
Inductive encoder
Protection Class
IP65
IP65
