MHD090B-035-NP0-UN by Bosch Rexroth Indramat
Get a Quote for MHD090B-035-NP0-UN
Request a quote or call us now at 1-919-443-0207!
In Stock, Ships Today
We respect your privacy. Your information is safe and will never be shared.
Secure Online
Checkout
Free Ground
Shipping
One Year
Warranty
The MHD090B-035-NP0-UN motor boasts a peak current of 49.5 amps, an insulation class F, and weighs 14 Kilograms. Part of the MHD Synchronous Motors series by Bosch Rexroth Indramat, it features IP65 protection and operates with a winding inductivity of 15.5 mH.
Technical Specifications
Winding inductivity
15.5 mH
15.5 mH
Insulation class (According to DIN VDE 0530 Part 1)
F
F
Degree of protection
IP65
IP65
Maximum installation elevation
1000 m above MSL
1000 m above MSL
Mass
14 Kg
14 Kg
Maximum speed
5000 RPM
5000 RPM
Driven Shaft
With Key
With Key
Characteristic motor speed
2500
2500
Peak Current
49.5 A
49.5 A
Number of pole pairs
4
4
