The MDD093C-N-020-N2L-110PL1 motor features a standard housing design and a shaft with keyway according to DIN 6885. Part of Bosch Rexroth Indramat's MDD Synchronous Motors series, it includes digital servo feedback and a nominal speed of 2000 min. This model offers an 11.0 Nm blocking brake and a centering diameter of 110 mm.
Technical Specifications
Motor For Digital Drive Controllers
MDD
MDD
Motor Size
093
093
Motor Length
C
C
Nominal Speed
2000 min
2000 min
Housing Design
Standard
Standard
Motor Feedback
Digital Servo Feedback
Digital Servo Feedback
Centering Diameter
110 mm
110 mm
Blocking Brake
With 11.0 Nm Blocking Brake
With 11.0 Nm Blocking Brake
Output Shaft
Shaft With Keyway Per DIN 6885 sh. 1, 8-68 Edition
Shaft With Keyway Per DIN 6885 sh. 1, 8-68 Edition
