The MAD100D-0200-SA-S2-AP0-05-A1 spindle motor delivers a maximum power of 23.2 kW, a maximum torque of 130 Nm, and a rated speed of 2000 rpm. Manufactured by Bosch Rexroth Indramat as part of their MAD Spindle Motor Series, it offers a continuous current at standstill of 28.7 A and rated power of 11.3 kW.
Technical Specifications
RATED TORQUE
54 Nm
54 Nm
RATED POWER
11.3 Kw
11.3 Kw
RATED CURRENT
27.2 A
27.2 A
RATED SPEED
2000 rpm
2000 rpm
KEY SPEED
1500 rpm
1500 rpm
MAXIMUM TORQUE
130 Nm
130 Nm
MAXIMUM POWER
23.2 Kw
23.2 Kw
MAXIMUM CURRENT
52.7 A
52.7 A
CONTINUOUS TORQUE AT STANDSTILL
59 Nm
59 Nm
CONTINUOUS CURRENT AT STANDSTILL
28.7 A
28.7 A
