Product Description
The B & R Automation X67DO1332 is part of the X67 Analog Input Output Series and features a robust IP67 degree of protection. This module offers 8 digital outputs at 24 VDC, with a nominal output current of 2 A, and thermal cutoff for overcurrent protection. Additionally, it has status indicators for each channel and operates in temperatures between -25 to 60°C.
Technical Specifications
| I/o Module | 8 digital outputs 24 VDC |
|---|---|
| Status Indicators | I/O function for each channel, supply voltage, bus function |
| Diagnostics - Outputs | Yes, using status LED and software |
| Connection Type - X2x Link | M12, B-keyed |
| Power Consumption - Internal I/o | 2 W |
| Power Consumption - X2x Link Power Supply | 0.75 W |
| Nominal Voltage | 24 VDC |
| Voltage Range | 18 to 30 VDC |
| Nominal Output Current | 2 A |
| Output Protection | Thermal cutoff for overcurrent and short circuit, integrated protection for switching inductances, reverse polarity protection for output power supply |
| Operating Temperature | -25 to 60 degrees C |
| Storage Temperature | -40 to 85 degrees C |
| Degree Of Protection | IP67 |
| Dimensions | Width: 53 mm, Height: 85 mm, Depth: 42 mm |
| Weight | 180 g |
