Product Description
The X20PS9400 is a digital output module by B & R Automation. As part of the X20 Fieldbus Input Output Series, it features an RS232 service interface. The module offers diagnostics for overload and status. It operates at 24 VDC and has a protection rating of IP20.
Technical Specifications
| Mounting Type | Panel Mount |
|---|---|
| Output Type | Digital |
| Input Voltage | 24 VDC -15% / +20% |
| Input Current | Max. 0.7 A |
| Output Voltage | 24 VDC |
| Output Power | 7 W |
| Interfaces | 1x RS232 service interface |
| Protection | IP20 |
| Operating Temperature | -25 to 60 degrees C (Horizontal), -25 to 50 degrees C (Vertical) |
| Storage Temperature | -40 to 85 degrees C |
| Dimensions | Width: 12.5 mm |
| Diagnostics | Overload, operating status, module status, RS232, using status LED and software |
