The X20DO8332 module offers eight 1-wire output connections. Made by B & R Automation, it is part of the X20 Fieldbus Input Output Series, and operates within a temperature range of -25 to 60 degrees Celsius (horizontal). It features output monitoring with a 10 ms delay and thermal cutoff protection.
Technical Specifications
Number Of Outputs
8
8
Output Current
2 A
2 A
Output Voltage
24 VDC
24 VDC
Total Nominal Current Per Module
8 A
8 A
Connection Type
1-wire connections
1-wire connections
Output Circuit
Source
Source
Output Protection
Thermal cutoff if overcurrent or short circuit occurs
Thermal cutoff if overcurrent or short circuit occurs
Diagnostics
Output monitoring with 10 ms delay
Output monitoring with 10 ms delay
Leakage Current When Off
5 uA
5 uA
Peak Short Circuit Current
<12 A
<12 A
Switching Delay
0 ? 1 <300 us, 1 ? 0 <300 us
0 ? 1 <300 us, 1 ? 0 <300 us
Switching Frequency (resistive Load)
Max. 500 Hz
Max. 500 Hz
Operating Temperature
-25 to 60 degrees C (Horizontal), -25 to 50 degrees C (Vertical)
-25 to 60 degrees C (Horizontal), -25 to 50 degrees C (Vertical)
