Product Description
The X20DI9371 input module has 12 digital inputs designed for 1-wire connections, operates at a nominal voltage of 24 VDC, and includes configurable input filters and operating state indicators. As part of the X20 Fieldbus Input Output Series by B & R Automation, the module features I/O function status indicators per channel and a power consumption of 0.18 W for the bus.
Technical Specifications
| Number Of Digital Inputs | 12 |
|---|---|
| Type Of Connection | sink |
| Connection Type | 1-wire connections |
| Configurable Input Filter | Yes |
| Status Indicators | I/O function per channel, operating state, module status |
| Power Consumption Bus | 0.18 W |
| Power Consumption External I/o | 1.75 W |
| Nominal Voltage | 24 VDC |
| Input Voltage | 24 VDC -15% / +20% |
| Type Designation | Other |
| I/o Module Description | 12 digital inputs 24 VDC for 1-wire connections |
| Extended Product Type | Other |
| Module Status Indicator | Yes |
| Operating State Indicator | Yes |
