The X20DC2396 is a part of the X20 Fieldbus Input Output Series by B & R Automation.
Technical Specifications
Input Voltage
24 VDC -15 % / +20 %
24 VDC -15 % / +20 %
Status Indicators
I/O function per channel, operating state, module status
I/O function per channel, operating state, module status
Diagnostics
Module run/error using status LED and software
Module run/error using status LED and software
Bus Power Consumption
0.01 W
0.01 W
Internal I/o Power Consumption
1.5 W
1.5 W
Type Of Signal Lines
Shielded cables
Shielded cables
Digital Input Quantity
2
2
Nominal Voltage
24 VDC
24 VDC
Digital Input Current At 24 Vdc
Approx. 3.3 mA
Approx. 3.3 mA
Digital Input Filter (hardware)
2 us
2 us
Digital Input Resistance
7.19 k?
7.19 k?
Switching Threshold (low)
<5 VDC
<5 VDC
Switching Threshold (high)
>15 VDC
>15 VDC
Internal Encoder Supply
600 mA
600 mA
Isolation Voltage Between Encoder And Bus
500 V
500 V
