X20CP1485 by B & R Automation
Get a Quote for X20CP1485
Request a quote or call us now at 1-919-443-0207!
We respect your privacy. Your information is safe and will never be shared.
Secure Online
Checkout
Free Ground
Shipping
One Year
Warranty
Product Description
The B & R Automation X20CP1485 is an advanced component from the X20 Fieldbus Input Output Series, designed for rigorous industrial environments. Powered by an Intel Celeron 400 Performance processor, this module ensures robust computing capabilities. It features a fan-free cooling design and accommodates CompactFlash for application memory. The unit offers multiple onboard interfaces including Ethernet, POWERLINK, and USB, enabling versatile connectivity. It is built to operate smoothly across a wide temperature range from 0 to 55 degrees C horizontally. Compliant with IP20 protection standards, it is well-suited for varied installation orientations.
Technical Specifications
| Processor | Intel Celeron 400 Performance |
|---|---|
| Additional Processor | I/O Processor |
| Onboard Interfaces | Ethernet, POWERLINK, USB |
| Interface Module Slots | 1 slot for modular interface expansion |
| Application Memory | CompactFlash |
| Cooling | Fan-free |
| Dimensions | {'Width': '150 mm', 'Height': '99 mm', 'Depth': '85 mm'} |
| Installation Orientation | {'Horizontal': 'Yes', 'Vertical': 'Yes'} |
| Installation Elevation (0-2000 M) | No limitation |
| Installation Elevation (>2000 M) | Reduction of ambient temperature by 0.5 degrees C per 100 m |
| Protection Degree (en 60529) | IP20 |
| Operating Temperature (horizontal) | 0 to 55 degrees C |
| Operating Temperature (vertical) | 0 to 50 degrees C |
| Storage Temperature | -25 to 70 degrees C |
| Transport Temperature | -25 to 70 degrees C |
