Product Description
The B & R Automation 8LSA35.E0030D100-0 is a reliable three-phase synchronous motor from the prestigious 8LS Synchronous Motor Series. This motor operates at a maximum speed of 6000 RPM and delivers a rated torque of 3 Nm with a peak torque capability of 9 Nm. Thanks to its natural convection cooling method, it ensures efficient operation while maintaining an IP65 protection class for durability. Equipped with a circular speedTEC plug and an incremental encoder, it offers precise feedback with options for resolver or absolute encoder (EnDat) systems. Weighing 4.3 kg and constructed using NdFeB permanent magnets, this motor is designed to uphold performance in demanding applications.
Technical Specifications
| Make | B&R |
|---|---|
| Type | Servo Motor |
| Motor Type | Three-phase synchronous motor |
| Encoder | Incremental encoder |
| Max Speed | 6000 RPM |
| Rated Torque | 3 Nm |
| Peak Torque | 9 Nm |
| Voltage | 230 V |
| Stator Material | NdFeB permanent magnets |
| Connector Type | Circular speedTEC plug |
| Protection Class | IP65 |
| Cooling Method | Natural convection |
| Weight | 4.3 kg |
| Feedback | Resolver or absolute encoder (EnDat) |
