Product Description
The B & R Automation 8LSA35.DB030S300-3 is a robust synchronous motor from the 8LS Synchronous Motor Series, ideal for precision applications. Operating on 400 V with natural cooling, it has a rated power of 0.61 kW and produces a rated torque of 1.95 Nm at 3000 RPM. Featuring IP65 protection, it can withstand challenging environments. Its maximum current of 14.3 A ensures peak performance, while the resolver feedback offers precise control. Weighing 3.9 kg, it’s compact yet efficient.
Technical Specifications
| Type | Synchronous Motor |
|---|---|
| Voltage | 400 V |
| Rated Speed | 3000 RPM |
| Rated Torque | 1.95 Nm |
| Maximum Torque | 5.6 Nm |
| Rated Power | 0.61 kW |
| Maximum Current | 14.3 A |
| Rated Current | 2.2 A |
| System Inertia | 0.049 kgm^2 |
| Feedback | Resolver (2.1 multi-turn) |
| Protection Class | IP65 |
| Cooling Type | Natural Cooling |
| Environmental Temperature | 0 to 40 degrees C |
| Weight | 3.9 kg |
