Product Description
The 8LSA35.DA030S000-3 is a synchronous motor by B & R Automation and a part of the 8LS Synchronous Motor Series. Operating at a nominal speed of 3000 rpm, it features a stall torque of 2.300 Nm with an impressively precise DA 2.2 inductive 32-line single-turn (EnDat) encoder. Designed with a self-cooling type A construction, the motor boasts a protection class of IP64. It utilizes a swivel, SCS connection direction and supports a single cable solution. The motor runs on 560 VDC and a centering diameter of 80 mm ensures compatibility.
Technical Specifications
| Nominal Speed | 3000 rpm |
|---|---|
| Stall Torque | 2.300 Nm |
| Number Of Pole Pairs | 4 pairs |
| Connection Direction | Swivel, SCS |
| Construction Type | Self-cooling, type A |
| Protection Class | IP64 |
| Centering Diameter | 80 mm |
| Voltage | 560 VDC |
| Brake Holding Torque | 0.00 Nm |
| Encoder Type | DA 2.2 inductive 32-line single-turn (EnDat) |
| Motor Type | Synchronous motor |
| Single Cable Solution | Yes |
| No Oil Seal | Yes |
