Product Description
The B & R Automation 8LSA25.D9060S200-3 is an advanced synchronous motor from the 8LS Synchronous Motor Series. Operating with a nominal speed of 6000 rpm, it is optimally powered by a main input voltage of 3x 400 VAC to 3x 480 VAC ~10%. The motor features a centering diameter of 40 mm and a stall torque of 0.600 Nm. Its Speedtec circular connector from Intercontec allows for flexible and secure connections using an angled connector (swivel). The motor also boasts a reliable IP65 protection class with oil seal for stable operation in diverse environments.
Technical Specifications
| Motor Type | Synchronous Motor |
|---|---|
| Number Of Pole Pairs | 4 |
| Nominal Speed | 6000 rpm |
| Stall Torque | 0.600 Nm |
| Connector Type | Angled Connector (Swivel) |
| Centering Diameter | 40 mm |
| Shaft Fit | j6 |
| Protection Class With Oil Seal | IP65 |
| Connection Type | Speedtec Circular Connector from Intercontec |
| Main Input Voltage On Servo Drive | 3x 400 VAC ... 3x 480 VAC ~10% |
| Torque Ripple | Low |
