The 8LSA25.D8060S200-3 synchronous motor offers a maximum torque of 2.4 Nm, a nominal power of 327 Watts, operates at a maximum speed of 9000 rpm, and features a stator inductance of 49.6 mH. Part of the 8LS Synchronous Motor Series by B & R Automation, it includes 4 pole pairs and delivers a nominal current of 0.71 Amperes.
Technical Specifications
Nominal Speed [rpm]
6000
6000
Number Of Pole Pairs
4
4
Nominal Torque [nm]
0.52
0.52
Nominal Power [w]
327
327
Nominal Current [a]
0.71
0.71
Stall Torque [nm]
0.6
0.6
Stall Current [a]
0.82
0.82
Maximum Torque [nm]
2.4
2.4
Maximum Current [a]
3.7
3.7
Maximum Speed [rpm]
9000
9000
Torque Constant [nm/a]
0.73
0.73
Voltage Constant [v/1000 Rpm]
43.98
43.98
Stator Resistance [?]
34.63
34.63
Stator Inductance [mh]
49.6
49.6
Electrical Time Constant [ms]
1.4
1.4
