8LSA35.DB060S000-3 by B & R Automation

The 8LSA35.DB060S000-3 is a three-phase synchronous motor produced by B&R Automation within the 8LS Synchronous Motors series. It is intended for servo axes that demand high-speed positioning in industrial automation lines. When paired with ACOPOS drives, the motor converts electrical input into regulated mechanical torque for machine tools, pick-and-place systems, and packaging stations. Its operating role suits coordinated axes that must accelerate, reverse, and settle quickly during repeated production cycles.

Electrical power and feedback are routed through a single-cable hybrid solution that terminates in a standard connector, reducing cabinet wiring and simplifying the motor connection. The motor uses self-cooling through free air circulation, so airflow around the housing must remain unobstructed during continuous operation. Position feedback is generated by an inductive EnDat sensor that uses the EnDat 2.2 protocol, allowing absolute data transmission over the same cable. A flange dimension of 91.3 mm supports direct attachment to machine frames or gearboxes. The rotor is designed for a rated mechanical speed of 6000 rpm, which suits fast indexing and other high-speed servo tasks.

Within its length class, the motor uses a standard bearing configuration without reinforced bearings, making it suitable for light to medium radial loads. The encoder provides 19/12 bits for single-turn and multi-turn data, which gives the drive detailed position information after startup and during motion. It also has a multi-turn range of 4096 revolutions for tracking shaft position across many turns without losing the stored count. The motor is supplied without a holding brake or oil seal, so those functions must be provided elsewhere when the application requires them. A smooth shaft end supports coupling to compatible hubs, and the unit is identified as Product Revision 3.
