8LSA35.DA030S200-3 by B & R Automation

The 8LSA35.DA030S200-3 synchronous servo motor is manufactured by B&R Automation and is part of the 8LS Synchronous Motors series. Designed for integration into compact machine modules, the unit converts three-phase electrical power into controlled mechanical rotation for positioning and speed-regulated tasks along automated production lines. Its design follows the 8LSA standard configuration, so the rotor bearings are not reinforced and inertia stays low for moderate radial loads in conveyor, pick-and-place, and packaging axes.

It reaches a rated speed of 3000 rpm, allowing mid-speed motion profiles without exceeding drive voltage limits. The mounting face measures 91.3 mm across the flange, so the motor mates directly with ISO size 90 gearheads or brackets. Power conductors and encoder signals share a single-cable solution, terminated on a keyed connector to simplify cabinet routing. Rotor position is monitored by an inductive EnDat sensor that uses the 2.2 protocol, which streams absolute position to the drive over the same hybrid lead. Heat is removed through self-cooling by free-air circulation, eliminating the need for external fans. A mounting flange is provided for face installation, and the absence of an oil seal limits the motor to dry areas. Product revision 3 identifies the current mechanical layout.

The motor includes a standard holding brake that clamps the shaft when the system is de-energized. The output end is a smooth shaft, suited for clamp or collet couplings where no keyway is required. Length code 5 corresponds to the active stack height and supports moderate continuous torque for medium load inertias. The encoder delivers an absolute resolution of 19/0 bits in single-turn format, giving the controller fine incremental data without the overhead of multi-turn counting. Because the unit is a three-phase synchronous design, it maintains constant torque up to rated speed.
