8LSA35.D9060S000-3 by B & R Automation

The 8LSA35.D9060S000-3 is a three-phase synchronous motor manufactured by B&R Automation within the 8LS Synchronous Motors series. It is designed for dynamic industrial axes and converts electrical power into controlled mechanical rotation for positioning tasks in packaging lines, pick-and-place modules, and material transfer systems. The standard 8LSA construction supports servo performance for fast and accurate motion while avoiding the added mass associated with reinforced bearing arrangements. This makes the motor suitable for applications that need responsive acceleration, precise speed control, and compact mechanical integration.

The motor reaches a rated speed of 6000 rpm, which supports short cycle times in high-throughput equipment. A 91.3 mm square flange provides the mounting interface to the machine frame and helps maintain alignment during operation. Heat is removed by a self-cooling design that relies on free air circulation, so no external blower is required. Rotor position is tracked by an Inductive EnDat feedback system that operates with version 2.2 and supplies 19/12-bit single-turn and multi-turn data. The standard 8LSA configuration does not include reinforced bearings, so shaft loads must remain within normal limits, and the design also omits a holding brake and an oil seal when the application requires static load holding or extra sealing.

Wiring is simplified by a single-cable solution that combines power conductors and digital feedback in one hybrid line, which helps reduce cable routing space around the axis. Mechanical attachment is handled by a mounting flange, and the smooth shaft allows direct clamp coupling without keyways to minimize backlash. The motor uses length code 5 for its stator stack height, and product revision 3 identifies the current build version. Absolute position is retained through a multi-turn counter that records up to 4096 revs, allowing the axis to retain position information after power is restored and reducing the need for a return-to-home sequence.
