Product Description
The 5D2210.01 control panel display by B & R Automation features a brightness of 200 cd/m2 with a lifespan of 25,000 hours. As part of the 5D2 Control Panel Display Series, it boasts a front frame made of polyester and measures 310 x 236 x 45 mm. It provides IP65 dust and spray protection from the front with a touch screen using resistive technology.
Technical Specifications
| Display Type | TFT Color, CFL background lighting |
|---|---|
| Resolution | VGA (640 * 480 pixels) |
| Display Diagonal | 10.4 in (264 mm) |
| Protection | IP65, dust and spray protection (from front) |
| Material | Aluminum eloxal coating |
| Design | Light grey |
| Touch Screen Technology | Accu Touch, Analog, resistive |
| Brightness | 200 cd/m2 |
| Brightness Life Span | 25,000 h |
| Environmental Temperature | 0 degrees CE" 50 degrees C, depending on installation |
| Weight | Approx. 2 kg |
| Outer Dimensions | 310 x 236 x 45 mm |
| Front Frame Material | Polyester |
| Gasket | Flat gasket around display front |
