Product Description
The 4PP015.0420-01 by B & R Automation is a versatile component from the 4PP Power Panel Series. Featuring an LCD display with 4 x 20 characters, it supports character sets in English and Katakana. Its digital interfaces include 16 inputs and 16 outputs, with the outputs rated at 0.5 A source, 24 VDC. Operating on a nominal voltage of 24 VDC, it is designed for temperatures from 0 to 50 degrees C. The panel boasts a 0.8 us instruction cycle time and provides 1024 kB Flashprom for storage. With IP65 protection and a weight of 0.584 kg, it is suitable for demanding environments.
Technical Specifications
| Nominal Voltage | 24 VDC |
|---|---|
| Display | LCD, 4 x 20 characters |
| Character Set | English / Katakana |
| Total Keys | 16 (12 with LEDs) |
| Digital Inputs | 16 channels, sink/source |
| Digital Outputs | 16 channels, 0.5 A source, 24 VDC |
| Flashprom | 1024 kB |
| Sram | 300 kB |
| Weight | 0.584 kg |
| Dimensions | 153 mm x 120 mm x 46.1 mm |
| Protection Class | IP65 (front) |
| Interfaces | 1 RS232, 1 CAN interface |
| Operating Temperature | 0 to 50 degrees C |
| Storage Temperature | -20 to 60 degrees C |
| Instruction Cycle Time | 0.8 us |
