CX5130-0135 by Beckhoff

Rated 4.7 stars (11 reviews)

Get a Quote for CX5130-0135

Request a quote or call us now at 1-888-551-3082!

In-Stock, Ships Today

We respect your privacy. Your information is safe and will never be shared.

Secure Online
Checkout

Free Ground
Shipping

One Year
Warranty

Beckhoff's CX5130 series of Embedded PCs features a compact, fanless design and low power consumption. These devices are powered by an Intel Atom E3827 multi-core processor clocked at 1.75 GHz. The series benefits from newer, more efficient processors that enable higher clock rates and reduced power consumption. Depending on the installed control software (supporting TwinCAT 2 and TwinCAT 3 (XAR) runtime environments), CX5130 PCs are versatile for implementing PLC or PLC/motion control projects with or without visualization. Available in various configurations with different control software and operating systems, the CX5130 series offers a top-tier option in terms of both price and performance.

Technical Specifications

Dimensions
142 mm x 100 mm x 92 mm

Processor
Dual-core Intel Atom® E3827

Processor Clock Rate
1.75 GHz

USB 2.0 Interfaces
4

Gbit Ethernet Interfaces
2

DVI-I Interface
Available

RAM
4GB DDR3

Maximum Power Consumption
20 W

Protection Category
IP20

MicroSD Card Slot
Available

Click here for product datasheet
