AX5203-0000-0200 by Beckhoff
Get a Quote for AX5203-0000-0200
Request a quote or call us now at 1-919-443-0207!
In Stock, Ships 2-3 Days
We respect your privacy. Your information is safe and will never be shared.
Secure Online
Checkout
Free Ground
Shipping
One Year
Warranty
The AX5203-0000-0200 boasts a maximum DC link voltage of 875 V DC. Part of Beckhoff's AX52xx Drive Series, it features a SERCOSĀ drive profile and measures 92 x 274 x 232 mm. The drive has a peak output current of 10 Amps and supports multiple feedback options including SinCos 1 Vpp and EnDat 2.1.
Technical Specifications
Dimensions (W x H x D)
92 x 274 x 232 mm
92 x 274 x 232 mm
Channels
2
2
Rated supply voltage
3 x 100Ā 480 V AC Ā±10 %
3 x 100Ā 480 V AC Ā±10 %
System bus
EtherCAT
EtherCAT
Approvals
CE, cULus, EAC
CE, cULus, EAC
Peak Output Current (RMS)1
10 Amp
10 Amp
DC link voltage
max. 875 V DC
max. 875 V DC
Protection category
IP 20
IP 20
Feedback
SinCosĀ 1Ā Vpp , resolver , EnDat 2.1 , Hiperface , BiSS B , OCT
SinCosĀ 1Ā Vpp , resolver , EnDat 2.1 , Hiperface , BiSS B , OCT
Drive profile
SERCOSĀ profile for servo drives according to IEC 61800-7-204 (SoE)
SERCOSĀ profile for servo drives according to IEC 61800-7-204 (SoE)
