AM3042-0E41-0000 by Beckhoff
Get a Quote for AM3042-0E41-0000
Request a quote or call us now at 1-919-443-0207!
Call For Quote
We respect your privacy. Your information is safe and will never be shared.
Secure Online
Checkout
Free Ground
Shipping
One Year
Warranty
The AM3042-0E41-0000 servomotor operates at 480 V AC with a rated torque of 2.81 Nm and reaches a peak torque of 13.0 Nm. Belonging to the AM Synchronous Servo Motors series from Beckhoff, it uses convection cooling and supports resolver, BiSS B and EnDat 2.1 feedback.
Technical Specifications
Cooling
convection
convection
Motor Type
synchronous servomotors
synchronous servomotors
Nominal Voltage
480 V AC
480 V AC
Peak Current
13.7 A
13.7 A
Rated Speed
3500 rpm
3500 rpm
Rated Torque
2.81 Nm
2.81 Nm
Torque Constant
1.26 Nm/A
1.26 Nm/A
